Eliminates failure-prone components in submerged applications, significantly reducing maintenance frequency and costs.
Optional high chrome alloy or rubber lining for all wetted components ensures excellent wear resistance in tough environments.
Allows free flow of large solids and fibers, reduces clogging and supports high concentrations of solids.
Provides reliable support for vertical shaft, isolates critical components from slurry contact.
Shaft lengths can be customized (up to 3 meters or more) to suit pit depth or tank dimensions.
| Parameter | Value |
|---|---|
| Flow Rate | 10 – 1200 m³/h |
| Head | 5 – 60 meters |
| Max Solid Size | Up to 50 mm |
| Operating Temperature | ≤ 80°C (higher optional) |
| Material Options | Cr26 high chrome, rubber, stainless steel |
| Submerged Depth | 900 – 3000 mm (customizable) |
| Drive Mode | Belt, direct coupling, motor mount |
Handling tailings, concentrate overflow, thickener underflow, and cyclone feed.
Pumping fine coal slurry, underflow pits, or slurry tanks.
Circulation of corrosive and abrasive chemical slurry in vertical tanks.
Fly ash slurry pumping in bottom ash pits or sedimentation sumps.
Sludge pumping from clarifiers or sludge collection basins.
The cantilever design requires no submerged seals or bearings. This eliminates the most common failure points in submerged environments, minimizing maintenance and preventing leakage issues.
For wetted parts, we provide options such as Cr26 high chrome alloy, rubber linings, and stainless steel to ensure optimum wear and corrosion resistance depending on the slurry type.
Yes. The shaft and submerged depth can be customized from 900 mm up to 3000 mm or more to precisely match your specific tank dimensions or pit depth.
Equipped with an open impeller in either a vortex or semi-vortex design, these pumps can efficiently handle large solids up to 50 mm in size without clogging.
The vertical slurry pumps can be configured with belt drives, direct coupling drives, or motor mount setups to best fit your plant space and speed control requirements.
